normalien-shop.de - Online Shop / Gleitplatten / Führungslasche VDI 3387

Führungslasche VDI 3387

Preis und Warenkorb erst nach Anmeldung sichtbar.

Artikelnummer: GLP10

Vergleichbar mit

2960.89
VDI 3387
VDI3387
3387

Dokumente

Varianten

Bestellnummer	d1	d	l1	l2	t	e	e1	Form	Anzahl Bohrungen	A	B	H	f	r
GLP10.063.36.224	20	14	20	90	16	50	36	A	3	224	63	36	18	16
GLP10.112.45.200	26	18	20	100	21	50	50	A	3	200	112	45	28	25
GLP10.090.36.250	26	18	20	100	21	50	50	A	3	250	90	36	28	25
GLP10.140.56.315	33	22	40	150	25.5	80	90	B	4	315	140	56	36	31.5
GLP10.112.45.250	26	18	20	100	21	50	50	A	3	250	112	45	28	25
GLP10.112.36.200	26	18	20	100	21	50	50	A	3	200	112	36	28	25
GLP10.090.45.250	26	18	20	100	21	50	50	A	3	250	90	45	28	25
GLP10.063.25.224	20	14	20	90	16	50	36	A	3	224	63	25	18	16
GLP10.140.45.315	33	22	40	150	25.5	80	90	B	4	315	140	45	36	31.5
GLP10.290.90.630	40	26	40	250	30.5	160	160	B	4	630	290	90	36	31.5
GLP10.290.90.500	40	26	40	250	30.5	160	160	B	4	500	290	90	36	31.5
GLP10.290.71.630	40	26	40	250	30.5	160	160	B	4	630	290	71	36	31.5
GLP10.290.71.500	40	26	40	250	30.5	160	160	B	4	500	290	71	36	31.5
GLP10.290.56.630	40	26	40	250	30.5	160	160	B	4	630	290	56	36	31.5
GLP10.290.56.500	40	26	40	250	30.5	160	160	B	4	500	290	56	36	31.5
GLP10.240.90.630	40	26	40	250	30.5	160	160	B	4	630	240	90	36	31.5
GLP10.240.90.500	40	26	40	250	30.5	160	160	B	4	500	240	90	36	31.5
GLP10.240.71.630	40	26	40	250	30.5	160	160	B	4	630	240	71	36	31.5
GLP10.240.71.500	40	26	40	250	30.5	160	160	B	4	500	240	71	36	31.5
GLP10.240.56.630	40	26	40	250	30.5	160	160	B	4	630	240	56	36	31.5
GLP10.240.56.500	40	26	40	250	30.5	160	160	B	4	500	240	56	36	31.5
GLP10.190.71.400	33	22	40	150	25.5	80	90	B	4	400	190	71	36	31.5
GLP10.190.71.315	33	22	40	150	25.5	80	90	B	4	315	190	71	36	31.5
GLP10.190.56.400	33	22	40	150	25.5	80	90	B	4	400	190	56	36	31.5
GLP10.190.56.315	33	22	40	150	25.5	80	90	B	4	315	190	56	36	31.5
GLP10.190.45.400	33	22	40	150	25.5	80	90	B	4	400	190	45	36	31.5
GLP10.190.45.315	33	22	40	150	25.5	80	90	B	4	315	190	45	36	31.5
GLP10.140.56.400	33	22	40	150	25.5	80	90	B	4	400	140	56	36	31.5
GLP10.140.45.400	33	22	40	150	25.5	80	90	B	4	400	140	45	36	31.5
GLP10.140.45.355	33	22	40	150	25.5	80	90	B	4	355	140	45	36	31.5
GLP10.112.45.224	26	18	20	100	21	50	50	A	3	224	112	45	28	25
GLP10.112.36.250	26	18	20	100	21	50	50	A	3	250	112	36	28	25
GLP10.112.36.224	26	18	20	100	21	50	50	A	3	224	112	36	28	25
GLP10.090.45.224	26	18	20	100	21	50	50	A	3	224	90	45	28	25
GLP10.090.45.200	26	18	20	100	21	50	50	A	3	200	90	45	28	25
GLP10.090.36.224	26	18	20	100	21	50	50	A	3	224	90	36	28	25
GLP10.090.36.200	26	18	20	100	21	50	50	A	3	200	90	36	28	25
GLP10.071.36.224	20	14	20	90	16	50	36	A	3	224	71	36	18	16
GLP10.071.36.200	20	14	20	90	16	50	36	A	3	200	71	36	18	16
GLP10.071.36.180	20	14	20	90	16	50	36	A	3	180	71	36	18	16
GLP10.071.25.224	20	14	20	90	16	50	36	A	3	224	71	25	18	16
GLP10.071.25.200	20	14	20	90	16	50	36	A	3	200	71	25	18	16
GLP10.071.25.180	20	14	20	90	16	50	36	A	3	180	71	25	18	16
GLP10.063.36.200	20	14	20	90	16	50	36	A	3	200	63	36	18	16
GLP10.063.36.180	20	14	20	90	16	50	36	A	3	180	63	36	18	16
GLP10.063.25.200	20	14	20	90	16	50	36	A	3	200	63	25	18	16
GLP10.063.25.180	20	14	20	90	16	50	36	A	3	180	63	25	18	16
